How To Choose The Power of Laser Welding Machine? Accurate Matching Based on Workpiece Thickness And Material

How to Choose the Right Laser-Welding Power

Too much power = wasted energy and burn-through; too little = lack of penetration and low speed. Stop guessing—just lock onto two things: work-piece thickness and material behavior. Match them exactly and you get quality, speed and low running costs. Here is the plain-English recipe.

1. Start with thickness: the “power rule-of-thumb”

Laser power sets weld depth—thicker metal needs more watts. Use stainless as the baseline and scale from there.

- Thin sheet (0.5–2 mm) → 500–1 000 W

 1 mm stainless: 800 W gives a flat, clean bead at 3–5 mm s⁻¹—ideal for electronics, small hardware.

- Medium plate (2–5 mm) → 1 000–2 000 W

 3 mm stainless: 1 500 W at 3–5 mm s⁻¹ gives full penetration without sluggish cycle times—perfect for auto parts, cookware.

- Thick plate (≥ 5 mm) → 2 000 W and up

 8 mm mild steel: 3 000 W in multi-mode achieves deep, strong joints for structural frames or pipes.

Remember: at the same power, slower travel = deeper weld; faster = shallower. Fix the watts first, then tune speed—never crank power blindly.

2. Factor in the metal: each one has a “power appetite”

Absorption and thermal conductivity change the game even at identical thickness.

 Stainless: absorbs well, medium conductivity—use the chart above straight.

 Mild steel: absorbs a bit less, conducts more; go ~20 % higher. 5 mm mild steel → 2 000 W instead of 1 500 W.

 Aluminum: highly reflective, super heat-sink. Needs more juice plus twin-pulse waveforms. 2 mm Al → 1 500 W minimum; 1 000 W gives porous, discontinuous beads.

 Copper: extreme reflectivity + conductivity. Surface prep (blackening) and ≥2 500 W for 3 mm Cu are mandatory.

3. Two field tricks to avoid buyer’s remorse

1. Always run a test coupon on scrap first. Check penetration, porosity, distortion—then fine-tune.

2. Build in a small buffer. If your parts vary 1–2 mm, pick the mid-level power (e.g. 1 000 W) so one machine covers the spread without constant re-settings.

Pick the laser power that matches real thickness and real material, and your welder will deliver maximum value—no wasted kilowatts, no weak joints.
